Type

Displacement

Max. Power

Max. Torque

Ingnition

Air cooled, 4 - stroke single cylinder OHC, Self Start

109 cc

6.0 kW ( 8.2 Ps ) @ 7500 rpm

9.10 N m @ 5500 rpm

CDI System

Cluch

Chassis Type

Dry, Automatic Centrifugal Clutch with variomatic drive.

High Rigidity Underbone Type.

Front

Rear

Bottom Link with spring loaded hydraulic dampers

Unit Swing with spring loaded hydraulic dampers

Front Brake

Rear Brake Drum

Drum; Internal expanding shoe type ( 130 mm ) (Combined Braking System)

Drum; Internal expanding shoe type ( 130 mm ) (Combined Braking System).

Tyre Size Front

Tyre Size Rear

90 / 100 x 10 - 53 J

90 / 100 x 10 - 53 J

Battery

Head Light

Tail Stop Lamp

Turn Signal Lamp

12 V - 3 Ah , MF Battery.

12V - 35W / 35W - Halogen Bulb ( Multi-Reflector Type ).

12V - 5W / 21 W ( Multi-Reflector Type).

12V- 10W ( Amber Bulb ) x 4 nos. ( Multi- Reflector - Clear Lens ).

Wheelbase

Ground Clearance

Fuel Tank Capacity

1240 mm

155 mm

5.3 litre ( Min )
