Engine
Type
Displacement
Max. Power
Max. Torque
Bore x Stroke
Compression Ratio
Starting
Ingnition
Engine oil grade
Air cooled, 4-stroke single cylinder OHC
124.7 CC
6.72 KW (9BHP) @ 7000 RPM
10.35 N-m @ 4000 RPM
52.4 x 57.8 mm
9.1 : 1
Self start / Kick start
AMI – Advanced Microprocessor Ignition System
SAE 10 W 30 SJ grade
Transmission & Chassis
Cluch
Gear box
Chassis Type
Multiplate wet
4 Speed constant mesh
Tubular double cradle type
Suspension
Front
Rear
Telescopic hydraulic shock absorbers
Swing arm with hydraulic shock absorber
Brakes
Front Brake
Rear Brake Drum
240 mm Dia: Pad – Non asbestos type
Internal expanding shoe type (130 mm) Liners – Non asbestos type
Wheels & Tyres
Rim Size Front
Rim Size Rear
Tyre Size Front
Tyre Size Rear
18 x 1.60, Spoke wheel / Cast wheel
2.75 x 18 – 42 P/ 4 PR
3.00 x 18 – 52 P / 6 PR
Electricals
Battery
12V-3 Ah, MF battery
12V-35W/35W-Halogen bulb (Multi – reflector tyre)
12V-5 / 21 W (Multi – reflector)
12V-10W (Amber bulb) x 4 nos (MFR – Clear lens)
Dimensions
Length
Width
Height
Wheelbase
Ground Clearance
Fuel Tank Capacity
Kerb Weight
2005 mm
735 mm
1070 mm
1265 mm
150 mm
13.6 Ltrs (Min)
125 Kg (Kick) / 129 Kg (Self)
Colors
