Engine
Type Displacement Max. Power Max. Torque Max. Speed Acceleration Bore x Stroke Carburettor Compression Ratio Starting Ingnition |
Air cooled, 4-stroke single cylinder OHC Power 223 CC 12.68 kW (17 BHP ) at 7000 rpm 18.35 N-m @ 6000 rpm 125 kmph 0 to 60 kmph In 3.8 Seconds 65.5 x 66.2 mm VE, constant vacuum carburetor with CCVI (Carb Controlled Variable Ignition) 9:1 Kick start + Self start AMI -Advanced Microprocessor |
Transmission & Chassis
Cluch Gear box Chassis Type |
Multiplate wet 5 Speed constant mesh Diamond Frame |
Suspension
Front |
Telescopic hydraulic shock absorbers Swing arm with 5 step adjustable type hydraulic shock absorber |
Brakes
Front Brake Rear Brake Drum |
Disc, Dia 276 mm Disc Internal expanding shoe type (130 mm) |
Wheels & Tyres
Tyre Size Front Tyre Size Rear |
2.75 x 18 -42P 100/90 x 18 - 56P |
Electricals
Battery Head Light Tail Stop Lamp Turn Signal Lamp |
12 V - 6 Ah, MF 7 (MF battery) 35W / 35W - Halogen bulb (Multi-reflector -D.C type) 5 / 21W x 2 Nos (Multi reflector) 21W x 4 Nos (Amber bulb) (Clear lens multi-reflector) |
Dimensions
Length Width Height Wheelbase Ground Clearance Fuel Tank Capacity Reserve Kerb Weight |
2125 mm 755 mm 1160 mm 1355 mm 150 mm 15 ltrs. (Min) 2 ltrs. 150 kgs |
